ELPM-S3LW

Objex

19,90 €

Sofort verfügbar, Lieferzeit: 1-2 Wochen

Produktnummer: 23025

Produktinformationen "ELPM-S3LW"

ELPM-S3LW Extremely low power module for IoT applications Combines LoRa and ESP into one module The ELPM-S3LW is a breakthrough for developers who develop battery-powered IoT devices and applications for power generation.

This innovative module combines the power of the ESP32-S3FN8 microcontroller with the Lora SX1262 long-range transceiver while focusing on minimal energy consumption.

Features:

Ultra Low Power Design: The ELPM-S3LW has an integrated power unit that adapts to your specific needs and minimizes energy consumption. With its deep stop mode, this module is ideal for applications where battery life is crucial.
Perfect for a variety of applications: Whether you're developing industrial solutions or general IoT devices, the ELPM-S3LW offers the flexibility and efficiency you need.
Efficiency oriented: With its focus on low energy consumption, the ELPM-S3LW is an excellent choice for projects that require long-lasting operating time and optimal energy use.

Technical data:

OBJEX ELPM S3LW/S3

ESP32-S3FN8 (32-bit, 240 MHz)
Memory Size: 8 MB Flash
GPIO: 33 available (7 reserved for LoRa - SPI)
WiFi - IEEE 802.11 b/g/n-compliant
Bluetooth 5/ Bluetooth LE
Interfaces: I²C, I²S, SPI, UART, USB
RGB status LED (WS2812B)
Deep Stop Mode, rising/falling edge detector & RTC (1-100 nA)
Footprint: 18 x 30 mm (0.71 x 1.18 in)
Weight: 2.30 grams (0.08 oz)

LoRa

Based on SX1262
Frequency bands: 862 MHz to 928 MHz
Signal power: 22 dBm
Transmission distance: 10 km
Communication interface: SPI
50 Ohm U.FL/pad antenna
Full compatibility with LoRa and LoRaWAN
